We have built up a modern factory for heavy-duty equipment, with a length of 290 meters and width of 109 meters. The factory is divided into three zones, North Zone, Middle Zone and South Zone, each of which is 34 meters wide.
The table below shows the machine distribution in every zone. The middle zone has a maximum hoisting capacity of 900T and now is equipped with a set of 450/100T crane.
Machine configuration table
Model
200/50T
75/20T
450/100T
125/32T
75/20T
300/50T
50/10T
Quantity
1 set
3 set
1 set
1 set
1 set
2 set
1 set
Hoisting height
18m
18m
25m
18m
18m
18m
18m
Zone
North
Middle
South
Processing Equipment
The North Zone is outfitted with these following machines, 2 sets of Φ200 floor-type NC boring and milling machine, 1 set of 4×12 m bridge-type NC milling machine, 1 set of 12m horizontal-type NC grinding machine, 1 set of Φ800 honing machine, 1 set of 3×4m NC gantry surface grinder and 1 set of Z33100×70 radial drilling machine.
Equipment in North Zone
Equipment in North Zone
Equipment in Middle Zone
Assembly zone
Large-scale equipment
Large-scale machines include 2 sets of Italy PAMA imported Φ260 floor-type NC boring and milling machines, 1 set of 16m NC boring machine, Φ1200 NC vertical press, 1 set of narrow gap welder and 1 set of stainless steel welder.
PAMA double-cylinder boring and milling machine
￠10000mm double-cylinder milling machine
Shown here is the gantry type NC milling and drilling machine, introduced from German Waldrich Coburg Company, with a size of 8000×51500mm.
This is gantry-moving type NC milling and drilling machine, with a size of 4000mm×12000mm.
